MatrixGold V3 launch June 2022
Bringing you new, time-saving features
MatrixGold adds a new dimension to Gemvision’s advanced CAD solutions. It combines top Matrix and RhinoGold features with the simplified interface of CounterSketch. MatrixGold offers you more power, a curated set of tools, intuitive workflow, and enhanced productivity.
What is MatrixGold
MatrixGold combines top Matrix and RhinoGold features with elements of the user-friendly CounterSketch interface. MatrixGold will simplify your work, resulting in greater productivity and easier customer participation.
Power
Rhino 8 CAD engine
– Developed using the latest version of McNeel’s Rhino 8 CAD engine.
– Provides outstanding speed for greater responsiveness.
– Improves presentation, display, and more.
Flexibility
Parametric history powered builders
– MatrixGold has enhanced data trees that retain — and remember — how components were built and how they relate to one another.
– Use this parametric history/memory to reconfigure design changes quickly.
Pre-production
Design reporting
– Improved volumising tools that help you to estimate manufacturing prices.
– Users have access to gem mapping, material lists, and additional reporting enhancements.
– Combination of features from the RhinoGold Tech Report and- Matrix Reporting tools that promote ease of use and customer value.
Advanced rendering
New rendering core
– MatrixGold builds on the Rhino 8 Cycles Engine to make rendering easy and intuitive.
– Allows GPU or CPU rendering to make the most of any computer system.
– Live preview rendering features material hot-swapping.
Designed in MatrixGold
Art is the science of creation and with MatrixGold creating has just become easier. Excite your clients with live changes by creating something amazing right in front of their eyes.
Contact us
Our GVUK Design team are here to help and advise on the best solution to your requirements, with full training and technical support.
T: 01582 727 971
E: sales@gvukdesign.co.uk
E: support@gvukdesign.co.uk
MatrixGold News
MatrixGold 3.8 Hotfix
Bugs:
• Fixed the issue with the Clayoo plugin loading.
• Fixed the issue with adding a profile to the library.
• Fixed the issue with the “F7” shortcut for the Hide/Show commands.
• Fixed the issue with custom containers:
Tools: Jali, Gem Placer, Pave, Gems Springs.
• Fixed the issue with Undo/Redo.
• Fixed the issue with gvLoft when saving and loading a file.
• Fixed the issue with displaying an incorrect distance when creating a hollow profile.• Fixed the issue with gvPullPush for Signet rings.
MatrixGold videos
Watch the magic with these short taster videos
MSR is back With Gems
MatrixGold Wed-Fit made easy.
And MSR Objects
Bespoke settings created from a collet using scallop cutter in MatrixGold with parametric history for easy editing.
Pull to rail is back
MatrixGold just 20 passes per frame.
Proxy Gem, just brilliant!
Learn how to create realistic French set with MatrixGold using cutters and parametric history.
Custom Gem, Better than ever
Watch and learn how easily you can set MatrixGold to render multiple versions with ease, 100’s of versions automatically rendered and saved to your destination folder.
Gem Placer – time saving Pave tool
Enjoy the flexibility to fully adjust your designs, changing gem shape & size, number of gems and layout allowing unlimited variations. Thanks to Michele Turco for this video.
